Selection Chart for Stick Welding Electrodes

Date: 21-04-2024

Selection Chart for Stick Welding Electrodes



Use this handy selection guide to help identify the best Weldclass stick welding rod for your project. Includes rods for welding steel, stainless-steel, cast-iron, hardfacing, and more.

Download Pdf Version of This Chart    View Chart for Brazing & TIG Rods



Type

Product

Click to view product details ↓

Applications / Attributes Operating Comments
Steel
General Purpose
PLATINUM 12V

Mild & galvanised steel.
Very popular due to exceptional user appeal.
Very smooth arc, easy re-striking & self-releasing slag.
Tolerant to dirty materials & poor fit-up.

Suitable for use with most welding machines.
Use in all positions, including vertical down.
PROMAX GP Mild & galvanised steel.
Supplied in 1kg re-usable packs.
Very smooth arc, easy re-striking & self-releasing slag.
Tolerant to dirty materials & poor fit-up.
Suitable for use with most welding machines.
Use in all positions, including vertical down.

SteelHigh Strength
(Low Hydrogen)

PLATINUM 16XT Where higher strength is required, eg highly restrained joints, components subject to higher load or sudden stress.
Twin-coated for excellent arc stability.
2kg vacuum-sealed packs keep electrodes moisture-free.
Should be used on machines with OCV of DC 55V or AC 65V & above.
Use in all positions, except vertical down.
PROMAX 16LH Where higher strength is required, eg highly restrained joints, components subject to higher load or sudden stress.
1kg re-usable packs keep electrodes in good condition.
Should be used on machines with OCV of 45-55V & above.
Use in all positions, except vertical down.
Stainless-Steel PLATINUM 316L Welding of matching 316, 316L & common 300 series stainless steels, including; 301, 302, 304, 304L, 3Cr12, etc. Good resistance to pitting, acids & general corrosion. Suitable for use with most welding machines.
Use in all positions, including vertical down.
PLATINUM 309MoL Strong & corrosion-resistant welding of; Stainless to mild or low alloy steels, Matching 309 & 309L stainless, CrNi & CrNiMo stainless, Hard to weld steels, Cladding & buffer layers. Should be used on machines with OCV of 70V & above.
Use in all positions, except vertical down.
Universal PLATINUM 312 High strength welding of almost any steel or stainless-steel. Ideal for; Unknown steels, Dissimilar steels (eg steel to stainless), Die or tool steel,
etc. Also used for buffer layer prior to hardfacing.
Suitable for use with most welding machines.
Use in all positions, including vertical down.
Cast Iron PLATINUM NiFe High strength, hot or cold welding of; cast iron (incl. grey / malleable, nodular & SG iron) & cast iron to steel. Machineable weld deposit. Suitable for use with most welding machines.
Use in flat / horizontal position only.
Hard Facing PROMAX 700 General use on ground-engaging implements & similar; augers, points, tynes, blades. Ideal for parts subject to flexing. Hardness 53-56 HRC. Suitable for use with most welding machines.
Use in flat / horizontal position only.
PLATINUM 943 High-performance for long wear life. Exceptional abrasion resistance & good impact strength. Bucket lips, screws, hammers, teeth, crushers, etc. Hardness 60-65 HRC. Should be used on machines with OCV of 55V & above.
Use in flat / horizontal position only.
