Scroll down ⇓⇓ to check out some of the recently-launched new or updated Weldclass products.



  • The ALLCLEAR® MX150M is a single-phase 230V mobile welding fume extraction and filtration unit (or "LEV"). Independently laboratory tested to and compliant with AS/NZS ISO 21904, achieving 99.93% whole-of-system efficiency and genuine W3 classification.
    At 59kg with a 0.43m2 footprint, and available in multiple configurations, this is one of the most compact and versatile LEVs on the market. Can be configured with a 3m extraction arm, a 10m flexible hose for hard-to-access locations, or a downdraft tabletop.
    Across the range, ALLCLEAR® LEVs are designed with extraction volume performance, spark management, and filter life as priorities, and the MX150M is no exception. Fan capacity of 2,500m3/hr maximises extraction volume, critical for helping workplaces achieve compliance with WEL fume limit requirements. A spark deflector system shields the filter from sparks and coarse particles, significantly reducing fire risk and increasing filter life. The cleanable and reusable sinTexx Plus nanofibre cartridge filter provides low pressure drop and long service life. An exhaust filter provides the 3rd safety filter stage and diffuses discharged air to reduce turbulence. An optional spark filter for the capture hood provides a 4th filtration stage and additional protection against fire risk.
    A special filter access door allows easy in-situ manual cleaning without removing the filter or exposing the operator to extracted material. Internally, particles separated by the spark deflector and dust ejected during filter cleaning collect in a dedicated drawer, accessed and cleaned from outside the unit. Low air flow / clogged filter visual and audible alarms and an hour meter take the guesswork out of maintenance scheduling. Operates off single-phase 230V 10A power supply. A great choice for general welding and grinding applications.

    Get a Quote | Request a Demo
  • The ALLCLEAR® MX250A is a single-phase 230V mobile welding fume extraction and filtration unit (or "LEV") with automatic filter cleaning and advanced features. Independently laboratory tested to and compliant with AS/NZS ISO 21904, achieving 99.91% whole-of-system efficiency and genuine W3 classification.
    Available with single or twin 3m extraction arms, or single or twin 10m flexible hose and hood with magnetic stand for hard-to-access locations. Auto start/stop syncs the unit with the welding machine via a current sensor that clips to the earth cable, or run in manual mode.
    Like all ALLCLEAR® units, it is designed with extraction volume performance, spark management and filter life as priorities. Fan capacity of 2,520m3/hr maximises extraction volume, critical for helping workplaces achieve compliance with WEL fume limit requirements.
    A market-leading Spark Trap system forces captured air and particles through multiple chambers before they reach the main filters, giving the highest level of spark protection and significantly reducing fire risk. Two sinTexx Plus nanofibre cartridge filters provide low pressure drop and long service life. An exhaust filter provides the 3rd safety filter stage and diffuses discharged air to reduce turbulence. An optional spark filter for the capture hood adds a 4th filtration stage and additional protection against fire risk.
    Automatic reverse-jet filter cleaning uses compressed air to restore airflow without lost shift time. Particles separated by the spark trap and dust ejected during cleaning collect in two drawers accessed and cleaned from outside the unit. The digital control panel includes a clogged-filter alarm, compressed-air check, hour meter, alarm log and language selection.
    The ideal choice for workshops requiring high-capacity extraction and efficiency.

    Get a Quote | Request a Demo
  • This downdraft table variant of the ALLCLEAR® MX150M is one of the most compact and versatile welding and grinding fume extraction tables on the market. It runs on a 230V 10A power supply, so it can be used in almost any facility. A 0.43m2 base unit footprint, overall weight 89kg and removable table top make it easy to transport and manoeuvre.
    It uses the same extractor unit as the MX150M mobile extractor (LEV), which is tested to and compliant with AS/NZS ISO 21904 W3**. Like all ALLCLEAR® units, it is designed with extraction volume performance, spark management and filter life as priorities. Fan capacity of 2,500m3/hr maximises extraction volume, critical for helping workplaces comply with WEL fume limits. A spark deflector system shields the filter from sparks and coarse particles, reducing fire risk and extending filter life. The cleanable, reusable sinTexx Plus nanofibre cartridge filter provides low pressure drop and long service life. An exhaust filter provides the 3rd safety filter stage and diffuses discharged air to reduce turbulence.
    A filter access door allows in-situ manual cleaning without removing the filter or exposing the operator to extracted material. Particles separated by the spark deflector and dust from filter cleaning collect in an internal drawer, emptied from outside the unit. Visual and audible low airflow/clogged filter alarms and an hour meter take the guesswork out of maintenance scheduling. The W1200 x D800mm table top can be swapped for a 3m extraction arm or 10m hose. A great choice for general welding and grinding applications.

    Get a Quote | Request a Demo
