MIG Welder Wire Feed Troubleshooting Guide

MIG welder wire feed not working? Wire jamming? Here's a checklist to help you identify the cause and optimise the performance of your MIG welder. These tips apply to virtually any make and model MIG welder.



Do's and dont's for successful wire feeding & great welds!

MIG wire feed system



More tips for specific Weldclass MIG machines





Check the basics first

We've all done it; cursed our machine and wasted time, only to find we've overlooked something basic.

Check these things first and you could save yourself a lot of time and hassle.

Earth lead & Clamp: Yep, one end connected to the welder & the other to the job!

Polarity: Check and double check you have the correct polarity for the wire you are using. Most "solid" wires should be used with Torch/Wire + and Earth -.  Gasless wires should be used with Torch/Wire - & Earth +.

Connections: This is far more important than what many welders realise. Just like a leaky garden hose, a loose connection anywhere along the current path will compromise the performance of your welder. Check that all connections are tight/firm and in good condition, including:  MIG torch and earth lead connection to the welder, any polarity connections (sometimes inside the wire feeder compartment), earth lead cables, any cable joints & lugs, earth clamp, etc.  Worn or damaged cables, connections and earth clamps should be replacedMore on this topic here.





Spool Hub Brake Tension

Spool tension should be enough to brake the spool & prevent free-wheeling. Do NOT over-tighten, as this will put undue strain on the drive system.



Drive Roller(s) Selection

It is important to select the right drive roller type to match the wire you are using. Here's a rule-of-thumb;

Solid Steel & Stainless wires: V-groove roller

Gasless & Flux-Cored wires: Knurled roller where possible (to grip the softer flux-cored wire). V-groove will often work OK as an alternative.

Aluminium wires: U-groove roller (a v-groove roller will squash softer Aluminium wire out of shape)

Bronze ("brazing") wires: U-groove where possible, otherwise V-groove

Drive rollers for Weldclass MIG welders





Drive Roller Alignment

Most drive rollers will have two grooves for different wire sizes. Make sure that the drive roller is installed so that the groove being used is the correct size for the wire size you are using.

VERY IMPORTANT:  Make certain that the wire is sitting directly & firmly inside the groove in the roller, before closing/locking the tension arm.



Wire Feed Tension Arm

Tension should be enough to maintain a consistent wire feed with no drive roller slippage, but no more.

Avoid the temptation to wind up / increase the tension as "instant fix" for wire feed issues.  Excessive feed tension will not only cause premature wear of the drive roller, bearings and motor/gearbox - but it can also 'squash' the wire out of shape and make the problem worse.  If wire is not feeding correctly, check for all other causes (as listed in this guide) first.



Contact Tips

Ensure that the contact tip in the torch is the correct size for the wire you are using.

If wire jamming occurs when the torch becomes hot, this is often because the heat causes the wire and the tip to expand (which shrinks the hole in the tip). This often occurs with gasless wire, where the torch will typically run hotter without the cooling effect of gas.  Using a slightly oversize tip can prevent this – eg: for 0.9mm wire, use a 1.0mm tip.

Aluminium wire also requires slightly "over size" tips. These will usually be available as a specific aluminium tip. For example a 1.0mm aluminium tip will be marked as "1.0A" or "1.0ALU".  These tips can also be used for gasless & flux-cored wire.

If the contact tip is worn (or is too large), this will result in wire arcing out inside the tip, causing wire jamming. If this is occuring replace the tip.

MIG Torch & Parts ID Guide





Torch Liner

Ensure that the liner (fitted inside the torch cable) is the correct type and size for the wire you are using.

Steel wires require a steel liner, Aluminium wires require a teflon or polymer liner.

Liners are typically available in size ranges, for example 0.6-0.8mm, 0.9-1.2mm and so on. If the liner is too small this will cause wire jamming, if too large it will allow the wire to 'snake' and jam.

Liners are a consumable part and should be replaced periodically as they gradually fill up with particles and wear internally.  There's no hard & fast rule, but if your MIG torch has done a lot of work and you're having wire feed problems it may be time to replace the liner.  Do NOT blow out the liner with compressed air!  It may be tempting to do this as quick fix, but A) This can damage the gas tube around the liner, and B) this won't improve the liner if it is worn & needs replacement.

MIG Torch & Parts ID Guide   How to fit steel liners   How to fit teflon (aluminium) liners





Isolate the cause

If you are having difficulty finding the cause of wire feed problems, isolating each area can help to identify which components may be causing problems, so you can address them and get welding again.

Firstly, remove the MIG torch from the machine (unless your machine has a direct-connect / hard-wired torch).

With torch removed from the machine, feed a length of wire (at least 2-3m longer than the torch) through the torch & then pull it through manually from the handpiece / contact tip end. Slight resistance / friction is normal , however if it requires strong force to pull the wire, this suggest that the problem is in the torch. Follow the suggestions above relating to the torch parts, including the contact tip & liner.

If you are very confident that the torch is OK, you can connect it back to the machine.  Otherwise, you can isolate and test the wire drive system in the machine with the torch removed;  First disconnect the earth lead for extra safety precaution.  Take a short legth of wire bent into a U-shape, and place this against both of the trigger socket terminals in the Euro torch connection on the front of the machine (see below). Note; these trigger terminals do not carry electrical current.  This will simulate the torch trigger function to active the drive system, and will allow you to observe if wire is feeding correctly from the machine.

Ensure spool hub tension is correct (as above).  You can also apply light hand pressure on the wire spool to simulate a normal level of drag/friction created by the torch. Then check to see if wire is feeding normally & that drive rollers are not slipping.

If drive rollers are slipping or wire feed is uneven, this suggest that the problem may be caused by the internal drive system parts. Follow suggestions above relating to spool hub brake, drive rollers & other internal parts.





Wire feed set up for specific Weldclass MIG welder models
